Inner and outer filter cotton green tea bag packing machine with with label and string

Inner and outer filter cotton green tea bag packing machine with with label and string


Application Suitable for: tea, medicinal tea, ginseng tea, coffee, Chinese herbal medicine, plants and other filter articles. Characteristic T ......

Email: [email protected]


Product detail

Inner and outer filter cotton green tea bag packing machine with with label and string

Application

Suitable for: tea, medicinal tea, ginseng tea, coffee, Chinese herbal medicine, plants and other filter articles.

Inner and outer filter cotton green tea bag packing machine with  with label and string

Characteristic

This machine is a new type of heat-sealed, multifunctional and fully automatic tea bag beverage packaging equipment.

The main feature of this machine is that the inner and outer bags are formed at one time, which avoids the direct contact

between human hands and materials and improves efficiency. The inner bag is made of filter cotton paper, which can be

automatically wired and labeled, and the outer bag is made of composite paper. Its biggest advantage lies in that both labeling

and outer bag can be positioned by photoelectric positioning, and the packaging capacity, inner bag, outer bag and label can be

adjusted at will, and the dimensions of inner and outer bags can be adjusted according to different needs of users, so as to achieve

the best packaging effect, improve the appearance grade of products and enhance the value of products.



Technical parameter

Packaging capacity 1-5g
Packaging speed(actural speed) 25-40 bags/min
Label size Width: 45mm length: 20mm
Line length 155mm
inner bag Width: 50-80mm length: 50-80mm,
Outer bag Width: 70-100mm and length: 80-120mm.
Electric source 220V 60Hz\110V 50HZ 1.18KW
External dimension (L×W×H)1600×700×2000mm
Overall weight 500Kg
