Ultrafine Vertical Grinding Mill Vertical Grading Ultra-micro Mill

Ultrafine Vertical Grinding Mill Vertical Grading Ultra-micro Mill

Vertical Grading Ultra-micro Mills are widely used in Positive electrode material of lithium battery, negative electrode material, Chinese herbal medicine, chemical medicine, dyestuff, pigment, cosmetic, resin, phosphate, flame retardant, silica, plastics, feed, plant fibre, recycled rubber, PE wax and other fields.

Working Principle of Vertical Grading Ultra-micro Mill

The material is evenly fed into the crushing room by the feeding system and is subject to the strong impact of the high-speed rotating crushing disc, and at the same time is subject to the role of centrifugal force, collision with the crushing ring, shear, friction, collision and other comprehensive force, so that the material is crushed, crushed materials with the airflow to the grading area, through the frequency-regulated grading wheel, the separation of coarse and fine materials, the product meets the requirements of the fineness with the airflow into the Cyclone collector and dust collector to collect, coarse materials return to the grading area for secondary crushing.

Parameters of Ultrafine Vertical Grinding Mill

Ultrafine Vertical Grinding Mill Performance Characteristics

Crushing and classifying integrated design, through the adjustment of the classification wheel to obtain the ideal product size.
Compact structure, small footprint, low installed power, wide range of applications, cost-effective.
According to the characteristics of the material, the crushing parts can be flexibly changed (bar, hammer, tooth, etc.) to obtain different crushing force and improve the crushing efficiency.
1.ACM air classification mill is the introduction of the latest German technology, after years of technical experience, the comprehensive performance of the equipment has been equivalent to the United States, Germany and Japan imported the same model;
2.Suitable for Moh’s hardness of 5 or less of a variety of powder crushing, dispersion and depolymerisation, spherical shaping and so on;
3.The fineness of the crushed material can be adjusted between 5~150μm, and the D50 value of some agglomerated loose materials can reach 2μm;
4.High wear-resistant: Hammer head, gear ring, grading impeller using wear-resistant new material processing production, special technology processing;
5.High stability: advanced structural design, the system air volume effectively reduces the material temperature rise and the temperature of the shaft system, can run continuously 24;
6.High environmental protection: the whole set of system closed crushing, collection, no dust leakage, low noise, clean and environmentally friendly production process;
7.Multi-purpose design: can be used in tandem with the classifier, vibrating screen, etc., for particle size distribution concentration, ultra-fine requirements;
8.Explosion-proof, air-cooled, heated design: nitrogen protection cycle process, to ensure the continuous and stable operation of easily oxidised hazardous materials;
